PRODUCT DESCRIPTION
Sliding door usually refer to those relatively light, easy-to-operate slidingdoors, mainly used for the access of people or smaller-scale goods, suitable foroccasions that do not require high-strength insulation or protection. This type of door has a simple design and is relatively easy to install and maintain.
- For positive temperature (-5°C min) and negative temperatures (up to -45)
- Blade thickness 100/150 mm
- Polyurethane density 42 Kg/m3
- Steel plate option: stainless steel, color steel plate, etc
- Door size option: Customized.
- Door structure type: Light duty / Heavy duty
- Door open type: Manual opening / Electric (motorized) opening
- Available in one blade or two blades versions
APPLICATIONS
Suitable for cold rooms used for the preservation of foods at a temperature up to –45°C
Mainly used in meat processing plants, cheese factories, warehouses to preserve fruit and vegetables, slaughters, trade centres, shops (delicatessens, fish shops, dairies, ice-cream parlours …), fish processing plants, ice-creams industry.
Sealing strip
It is made of EPDM material, with good chemical resistance, excellent aging resistance, wide temperature adaptability, and long-term working temperature of -50℃~+130℃.
Door panel
Polyurethane and panel are foamed in one piece, with a smooth appearance and good thermal insulation performance.
Panel material: stainless steel, color steel plate, embossed aluminum plate.
Door frame
It is made of aluminum alloy as the door frame, which has a neat and generous appearance, is sturdy and durable, and overcomes the shortcomings of low strength and easy decay of wooden door frames. It is equipped with a self-limiting temperature electric belt, without temperature control or manual power switching.
Guide rail device
The guide rail is made of aluminum alloy, and the guide wheel device cooperates with the pressure wheel device to separate the door from the door frame when it is opened, and press the door frame and the ground when it is closed.
